- Take-off weight: Approximately 135 grams
- Dimensions: 130 × 157 × 48.5 mm (L × W × H)
- Maximum flight time: About 18 minutes (17 minutes with propeller guards)
- Maximum flight distance: 7 km or about 4 miles
- Maximum wind speed resistance: 8 m/s (Level 4)
- Operating temperature: -10° to 40° C (14° to 104° F)
- Internal storage: 22 GB (SD card not supported)
Flight Capabilities
The Neo offers versatile flight modes and precise control:
- Maximum rate of climb: 0.5 m/s (Cinema mode), 2 m/s (Normal mode), 3 m/s (Sports mode)
- Maximum descent speed: 0.5 m/s (Cinema mode), 2 m/s (Normal and Sports modes)
- Maximum horizontal speed: 6 m/s (Normal mode), 8 m/s (Sport mode), 16 m/s (Manual mode)
- Maximum take-off altitude: Measured at 2000m altitude with 120m vertical climb in sports mode (100% to 20% battery)
- Hover accuracy:
- Vertical: ±0.1 m (visual positioning), ±0.5 m (GNSS)
- Horizontal: ±0.3 m (visual positioning), ±1.5 m (GNSS)
Camera and Imaging
The Neo’s camera system is equally noteworthy:
- 1/2-inch image sensor
- Lens: FOV 117.6°, 14mm equivalent, f/2.8 aperture, 0.6m to ∞ focus
- ISO range: 100-6400 (automatic and manual)
- Maximum image size: 12 MP (4000 × 3000 in 4:3, 4000 × 2256 in 16:9)
- Video resolution: Up to 4K at 30fps with EIS on
- Maximum video bitrate: 75Mbps
- Shutter speed: Video 1/8000-1/30 s, Photo 1/8000-1/10 s
- Still photography modes: Single/timed shot
- Photo format: JPEG
- Video format: MP4
- File system: exFAT
Transmission and Connectivity
The drone utilizes DJI’s O4 transmission system:
- Live view quality: Up to 1080p/30fps with DJI RC-N3 Remote Control
- Operating frequency: 2.4 GHz, 5.1 GHz, and 5.8 GHz bands
- Maximum transmission distance: Varies by region, up to 10 km (FCC)
- Communication bandwidth: Max. 40 MHz
- Transmitter Power (EIRP):
- 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
- 5.1 GHz: <23 dBm (CE)
- 5.8 GHz: <26 dBm (FCC), <14 dBm (CE), <26 dBm (SRRC)
- Range with interference:
- Strong (cityscape): 1.5-3 km
- Medium (suburban): 3-6 km
- Low (Suburb/Seaside): 6-10 km
Global Navigation
The Neo supports multiple satellite systems:
- GLONASS + GPS + Galileo + BeiDou
